Details:
Signal Mode NTSC/PAL automatically suitable
Display 2.5 inch LCD screen, 960 x 240 resolution
Video Input 1 channel BNC
Video Output 1 channel BNC
PTZ Controlling
Communication RS232, RS422 simplex and RS485
Protocol Pelco D, P; Samsung, Panasonic or customized
Baud Rate 2400,4800,9600,19200
Other Function:
Signal Generating Output 1 channel video signal for testing monitor, PAL/NTSC selectable
UTP Cable Test Test UTP cable connection state and display in the screen
RS485 Data Test Test the RS485 data sent from controlling device
OSD Menu English OSD menu
Keyboard New design with number buttons, easy to operation
